| İlan No | 2138 |
|---|---|
| İlan Tarihi | 21 Temmuz 2026 |
| Marka | Forklift |
| Seri | Zoomlion |
| Model Yılı | 2026 |
| Yakıt Tipi | Elektrikli |
| Asansör Tipi | Tripleks |
| Asansör (m) | 4800 |
| Tonaj (ton) | 15/18/20 |
| Kimden | Mağazadan |
| Durumu | Sıfır |
| Specifications | Unit | FB10 | FB15 | FB20 | FB25 | FB30 | FB35 | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Characteristics | Power | battery | battery | battery | battery | battery | battery | |||||||
| Capacity | kg | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | |||||||
| Center of load | mm | 500 | 500 | 500 | 500 | 500 | 500 | |||||||
| Lifting height | mm | 3000 | 3000 | 3000 | 3000 | 3000 | 3000 | |||||||
| Free lifting height | mm | 135 | 135 | 145 | 145 | 145 | 150 | |||||||
| Forks L×W×H | mm | 920×100×35 | 920×100×35 | 1070×122×40 | 1070×122×40 | 1070×125×45 | 1070x125x50 | |||||||
| Mast tilt angle Forward/Backward | 。 | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 | 6/12 | |||||||
| Min.turning radius | mm | 1850 | 1850 | 2090 | 2090 | 2245 | 2385 | |||||||
| Min. right angle stacking width | mm | 3460 | 3460 | 3760 | 3760 | 3930 | 4065 | |||||||
| Min. right angle Aisle width | mm | 1840 | 1840 | 2040 | 2040 | 2120 | 2290 | |||||||
| Min.ground clearance | mm | 100 | 100 | 110 | 110 | 120 | 120 | |||||||
| Overhead guard height | mm | 2100 | 2100 | 2150 | 2150 | 2170 | 2300 | |||||||
| Height from seat to overhead guard | mm | 1005 | 1005 | 1005 | 1005 | 1005 | 1100 | |||||||
| Front overhang | mm | 405 | 405 | 470 | 470 | 475 | 485 | |||||||
| Perf | Max.traveling speed(loaded) | km/h | 12 | 12 | 13 | 13 | 13.5 | 13 | ||||||
| Max.lifting speed（loaded） | mm/s | 280 | 300 | 270 | 300 | 280 | 300 | 270 | 300 | 280 | 320 | 280 | ||
| Gradeability | % | 15 | 15 | 15 | 15 | 15 | 12 | |||||||
| Dimensions | Overall length （without fork） | mm | 1990 | 1990 | 2310 | 2310 | 2511 | 2630 | ||||||
| Overall width | mm | 1070 | 1070 | 1150 | 1150 | 1225 | 1225 | |||||||
| Mast extended height(with bracket) | mm | 3860 | 3860 | 4030 | 4030 | 4264 | 4264 | |||||||
| Mast lowered height | mm | 1955 | 1955 | 1990 | 1990 | 2055 | 2095 | |||||||
| Chassis | Tire | Front | 6.50-10-10PR | 6.50-10-10PR | 7.00-12-12PR | 7.00-12-12PR | 28×9-15-12PR | 28x9-15 | ||||||
| Front | 6.50-10-10PR | 6.50-10-10PR | 7.00-12-12PR | 7.00-12-12PR | 28×9-15-12PR | 28x9-15 | ||||||||
| Rear | 5.00-8-10PR | 5.00-8-10PR | 18×7-8-14PR | 18×7-8-14PR | 18×7-8-14PR | 18x7-8 | ||||||||
| Wheelbase | mm | 1250 | 1250 | 1450 | 1450 | 1600 | 1720 | |||||||
| Tread width | Front/Rear | mm | 890/920 | 890/920 | 960/950 | 960/950 | 1000/980 | 1000/980 | ||||||
| Curb weight | None-load | kg | 2800 | 2990 | 3950 | 4050 | 4810 | 5300 | ||||||
| Powertrain | Battery | Voltage/Capacity | V/Ah | 48/450 | 48/450 | 48/630 | 48/630 | 80/500 | 80/560 | |||||
| Motor | Traveling | KW | 8 | 8 | 11 | 11 | 12 | 12 | ||||||
| Lifting | KW | 7.5 | 10 | 7.5 | 10 | 10 | 14 | 10 | 14 | 12 | 14 | 14 | ||
| Controller | CURTIS | CURTIS | CURTIS | CURTIS | CURTIS | CURTIS | ||||||||
| Control type | 50%AC | 100%AC | 50%AC |
